Anti-Glare Downlight Dark series

Function:

  • Totally suppressing the lighting feel, blending into the space
  • Modulized light source for saving cost of maintenance and inventory
  • Anti-glare design : UGR<16, some series is UGR< 9
  • Cut off angle: 45ﾟ
  • SDCM<3
  • High efficiency: 90~100lm/ W for whole luminaire
  • Flicker free
  • Patent design of appearance: you won't find similarity in the market

Enquête Arrière
    • Description



Modulized light source design





PC Lens for different angles





Feature





Comparison

Dark series: it could blend into the surroundings, generating the lighting but suppressing all the lighting feel. Normal type: you can see the lighting.



Cutting Hole 125 mm
Luminaire Flux 800 lm/ 1000 lm/ 1500lm/ 2500lm
Power 8.6W/ 10.8W/ 16.5W/ 32.2W
LED Chip CREE or Philips
Input Voltage 100-240V AC
Cut off angle 45ﾟ
Beam Angle 16ﾟ/22ﾟ/43ﾟ/50ﾟ
Color temperature 2700K/ 3000K/ 3500K/ 4000K/ 5000K
SDCM <3
THD <15%
CRI 80/ 90/ 95
