Explosion-proof LED Linear Light

  • Degree of Protection - IP67 / NEMA 6
  • IECEx Certification:
Ex nR IIC T4...T5 Gc
Ex tb IIIC T115˚C...T100˚C Db
  • ATEX Certification
II 3 G Ex nR IIC T4...T5 Gc
II 2 D Ex tb IIIC T115˚C...T100˚C Db
  • Application: Zone 2/ Zone 21







Enquête Arrière
Précédent Prochain
  • Description
Model number L1915
Wattage 120W / 140W / 150W / 180W / 200W / 220W / 250W
Voltage 110V / 120V / 220V / 230V / 277V / 347V / 480V AC
CCT 3000K (Warm White) / 5000K (Cool White)
Lm (clear cover) Cool White≧115 lm/W, Warm White≧105 lm/W
Beam Angle X-113° / Y-115°
Protection IP67 / NEMA 6
Material
  • Enclosure: Aluminum alloy

  • Cover: PC Cover (Clear or Diffuser)
Installation Ceilling type/ Wall Mount/ Hanging Mount/ Pendant/ Stanchion
